Sonoff Wifi Dimmer

The Sonoff WiFi Dimmer is engineered to provide stable, smooth dimming control for LED, incandescent, and halogen lamps. It is compact, easy to install, and designed to fit into existing wall switch boxes. Beyond dimming, it offers real-time energy monitoring and overheat protection, ensuring both efficiency and safety. Its Matter compatibility future-proofs it for evolving smart home standards, making it a versatile choice for homeowners and installers.

Key Features

• Matter compatibility: Works with Apple Home, Google Home, and Amazon Alexa.
• Wide lighting support: Dimmable LEDs up to 200VA, incandescent/halogen up to 400W, electronic transformers up to 200W.
• Smooth calibrated dimming: Automatic/manual calibration for flicker-free performance.
• Real-time energy monitoring: Track consumption and optimize efficiency.
• Overheat protection: Automatically cuts power if temperatures rise too high.
• Zero ghosting design: Eliminates RF interference for stable operation.
• Compact installation: Fits standard mounting boxes with trailing-edge dimming technology.

Technical Specifications

• Model: Sonoff MINI-DIM
• Voltage Input: 100–240V AC, 50/60Hz
• Max Load: LED: 200VA, Incandescent/Halogen: 400W, Electronic Transformer: 200W
• Wireless Standard: WiFi 2.4GHz, Matter-enabled
• Dimming Technology: Trailing-edge dimming
• Dimmable LED: Up to 200VA
• Energy Monitoring: Real-time consumption tracking
• Safety Features: Overheat protection, automatic cut-off
• Dimensions: 54 × 45 × 24 mm (approx.)
• Compatibility: Apple Home, Google Home, Amazon Alexa
• Installation: Fits standard wall switch boxes
• Working Temperature: -10°C ~ 40°C
• Colour: White
